Charging relay (voltage regulator) from DZE Argentina equivalent to Shindengen SH6890A for Honda CB FY SC40 1300 (1998-2001) / CB X4 DCV SC38 1300 (1997-2000) / CB X4 DCW SC38 1300 (1997-2000) / CB X4 DCY SC38 1300 (1997-2000) / CB X4 DCX SC38 1300 (1997-2000) / CB FW SC40 1300 (1998-2001) / CB FX SC40 1300 (1998-2001) / VFR FiW/FiX 800 (1998-1999).
OEM part reference: 31600-MBG-305 / 31600MBG305.
Technical specifications
- voltage: 12 V
- power: 35 A
- input current: three-phase
- technology: SCR
- output type: direct current (D.C.)
- height: 41 mm
- width: 84 mm
- length: 108 mm
- hole spacing: 80 mm
- with sensor: no
