Charging Relay - Honda GL L Goldwing 1200 ('85) / GL SEI Goldwing 1200 ('86) - DZE

Charging relay (voltage regulator) from DZE Argentina for Honda GL L Goldwing 1200 (1985) / GL SEI Goldwing 1200 (1986).

OEM part reference: 31600-MG9-951 / 31600-ML8-305.

Technical specifications
- voltage: 12 V
- power: 35 A
- input current: three-phase
- technology: SCR
- output type: direct current (D.C.)
- height: 28 mm
- width: 80 mm
- length: 107 mm
- hole spacing: 74 mm
- with sensor: yes
