Charging relay - Piaggio Beverly / MP3 / X10 / X7 / BV / Aprilia SRV - DZE

Charging relay (voltage regulator) from DZE Argentina for Aprilia SRV 4T 8V E3 850 (2012-2013) / Piaggio BV ST 4T 4V IE E4 ABS 350 (2017-2018) / BV 4T 4V IE E3 350 (2012-2015) / Beverly 4T 4V IE SPORT TOURING 350 (2013-2014) / Beverly IE ABS 300 (2016-2017) / Beverly 4T ST IE ABS E4 350 (2017-2018) / MP3 LT BUSINESS 500 (2014-2016) / MP3 LT BUSINESS-SPORT ABS 300 (2014-2015) / MP3 LT SPORT 500 (2014-2015) / MP3 SPORT ABS 500 (2015-2018) / MP3 SPORT BUSINESS ABS 500 (2015-2017) / X10 4T 4V I.E. E3 500 (2012-2013) / X10 4T 4V I.E. E3 125 (2012-2013) / X10 4T 4V I.E. E3 350 (2012-2015) / X7 IE EURO 3 125 (2009) / X7 IE EURO 3 300 (2009).

OEM part reference: 641543 / 641711 / 4 34406206 J / 58209R.

Technical specifications
- voltage: 12 V
- power: 35 A
- input current: three-phase
- technology: MOSFET
- output type: direct current (D.C.)
- height: 41 mm
- width: 84 mm
- length: 108 mm
- hole spacing: 80 mm
- with sensor: no
