Kit piston - Kawasaki KX 85 ('04-'20) - 85 2T - ProX

Please select the piston size from the box above.

ProX piston kit for Kawasaki KX 85 (2014-2020) - 85cc 2T. The complete application list can be found below.

Technical specifications:
- standard cylinder diameter (factory diameter): 48.50 mm
- engine type: 2-stroke
- total piston length (B): 54.00 mm
- piston pin diameter (C): 14.00 mm
- compression height (D): 19.00 mm
- pin ring position measured from center (E): 18.00 mm
- pin ring position measured from center (F):
- internal piston pin distance (G): 17.50 mm
- piston head shape: domed
- manufacturing technology: cast piston

Available piston sizes (A):
- A (48.45 mm)
- B (48.46 mm)
- C (48.47 mm)
