Forged piston kit Wossner for Yamaha YZ 125 2T manufactured between 1986-1988.
The kit includes piston, ring, pin, and clips.
Please select the piston size from the box above.
Technical specifications:
- cylinder diameter: 56.00mm
- thermal clearance: 0.06mm
- pin-to-cap distance (measured from the center of the pin): 30.00mm
- piston pin dimensions: 16x10x45mm.
Available piston sizes:
- standard (55.94 mm)
- +0.50 mm (56.44 mm)
- +0.75 mm (56.69 mm)
- +1.00 mm (56.94 mm)
- +1.25 mm (57.19 mm)
- +1.50 mm (57.44 mm)
- +2.00 mm (57.94 mm)
