Oil temperature gauge - JM for Honda VTX 1300 (2003-2007).
Technical specifications:
- Alternative: JMT.7090098;
- Oil temperature gauge 24 x 3.0 mm with analog display;
- The original oil fill plug must be replaced with the temperature probe;
- Please note that the measuring probe is often only moistened with discarded oil;
- For example, a measurement on the oil drain plug provides a different value;
Note: Please carefully compare the thread diameter, pitch, and length of the oil dipstick with the replacement part!
WARNING: The air bubble in the sight glass ensures the expansion of the oil when heated.
Dimensions:
- Total length of the probe: 145 mm;
- Exposed length of the probe: 125 mm.
The complete application list can be found below.
