Forged piston kit Wossner for Honda TRX 450 R manufactured between 2004-2005.
The kit includes piston, rings, pin, and clips.
Please select the piston size from the box above.
Technical specifications:
- cylinder diameter: 94.00mm
- thermal clearance: 0.05mm
- number of rings: 3 (two compression / one oil)
- compression ratio: 10.50:1 (OEM)
- pin-to-head distance (measured from the center of the pin): 26.00mm
- piston pin dimensions: 21x13.5x51mm.
Available piston sizes:
- A (93.95mm)
- B (93.96mm)
- C (93.97mm)
