Forged piston kit Wossner for Honda TRX 450 R manufactured between 2006-2009.
The kit includes piston, rings, pin, and clips.
Please select the piston size from the box above.
Technical specifications:
- cylinder diameter: 96.00mm
- thermal clearance: 0.05mm
- number of rings: 3 (two compression / one oil)
- compression ratio: 12.00:1 (OEM)
- pin-to-head distance (measured from the center of the pin): 23.80mm
- pin dimensions: 19x10x51mm.
Available piston sizes:
- A (95.95mm)
- B (95.96mm)
- C (95.97mm)
- +2.00mm.
