Piston Kit - Husqvarna WMX125 / WR125 ('88-'91) (55.95-56.95mm) - Wossner

Forged piston kit Wossner for Husqvarna WMX 125 / WR 125 manufactured between 1988-1991.

The kit includes piston, ring, pin, and clips.

Please select the piston size from the box above.

Technical specifications:
- cylinder diameter: 56.00mm
- thermal clearance: 0.05mm
- pin-to-cap distance (measured from the center of the pin): 25.00mm
- piston pin dimensions: 16x10x45mm.

Available piston sizes:
- A (55.95 mm)
- B (55.96mm)
- C (55.97mm)
- +0.50mm
- +1.00mm
