Piston Kit - KTM SX 520 / EXC 520 ('00-'02) (94.95-96.95mm) - Wossner

Forged piston kit Wossner for KTM SX 520 / EXC 520 manufactured between 2000-2002.

The kit includes piston, rings, pin, and clips.

Please select the piston size from the box above.

Technical specifications:
- cylinder diameter: 95.00mm
- thermal clearance: 0.05mm
- pin-to-cap distance (measured from the center of the pin): 23.50mm
- piston pin dimensions: 20x13x51mm.

Available piston sizes:
- A (94.95 mm)
- B (94.96mm)
- C (94.97mm)
- +1.00mm (95.95mm)
- +2.00mm (96.95mm)
