Piston Kit - KTM SX-F450 ('07-'12) (96.96-96.98mm) - Wossner

Forged piston kit Wossner for KTM SX-F 450 4T manufactured between 2007-2012.

The kit includes piston, rings, pin, and clips.

Please select the piston size from the box above.

Technical specifications:
- cylinder diameter: 97.00mm
- thermal clearance: 0.04mm
- number of rings: 2 (one compression / one oil)
- compression ratio: 12.50:1 (OEM)
- pin-to-head distance (measured from the center of the pin): 21.30mm
- piston pin dimensions: 19x10x51mm.

Available piston sizes:
- A (96.96mm)
- B (96.97mm)
- C (96.98mm)
