Piston Kit - KTM SX85 ('03-'16) / Husqvarna TC85 ('14-'16) (46.95-46.97mm) - Wossner

Forged piston kit Wossner for Honda KTM SX 85 (2003-2016) / Husqvarna TC 85 (2014-2016).

The kit includes piston, ring, pin, and clips.

Please select the piston size from the box above.

Technical specifications:
- cylinder diameter: 47.00mm
- thermal clearance: 0.05mm
- pin-to-cap distance (measured from the center of the pin): 21.70mm
- piston pin dimensions: 12x8x37.5mm.

Available piston sizes:
- A (46.95 mm)
- B (46.96mm)
- C (46.97mm)
