Piston Kit - Kawasaki KX250F ('06-'09) (76.96-82.96mm) - Wossner

Forged piston kit Wossner for Kawasaki KX 250 F manufactured between 2006-2009. The kit includes piston, rings, pin, and clips.

Please select the piston size from the box above.

Technical specifications:
- cylinder diameter: 77.00mm
- thermal clearance: 0.04mm
- number of rings: 2 (one compression / one oil)
- compression ratio: 13.50:1
- pin-to-head distance (measured from the center of the pin): 19.60mm
- piston pin dimensions: 16x9x45mm.

Available piston sizes:
- A (76.96mm)
- B (76.97mm)
- C (76.98mm)
- +3.00mm (79.96mm)
- +6.00mm (82.96mm)
