Piston Kit - Suzuki RM-Z450 ('05-'07) (95.46-99.96mm) - Wossner

Forged piston kit Wossner for Suzuki RM-Z 450 manufactured between 2005-2007.

The kit includes piston, rings, pin, and clips.

Please select the piston size from the box above.

Technical specifications:
- cylinder diameter: 95.50mm
- thermal clearance: 0.04mm
- number of rings: 2 (one compression / one oil)
- compression ratio: 12.00:1 (OEM)
- pin-to-head distance (measured from the center of the pin): 22.30mm
- piston pin dimensions: 19x10x51mm.

Available piston sizes:
- A (95.46mm)
- B (95.47mm)
- C (95.48mm)
- +2.00mm (97.46mm)
- +4.50mm (99.96mm)
