Piston kit - Honda MTX 125 Rally ('88-'90) (55.96-55.99mm) - Wossner

Forged piston kit Wossner for Honda MTX 125 Rally manufactured between 1988-1990.

The kit includes piston, rings, pin, and clips.

Please select the piston size from the box above.

Technical specifications:
- cylinder diameter: 56.00mm
- thermal clearance: 0.04mm
- pin-to-cap distance (measured from the center of the pin): 30.60mm
- piston pin dimensions: 16x10x45mm.

Available piston sizes:
- A (55.96 mm)
- B (55.97 mm)
- C (55.98 mm)
- D (55.99 mm)
