Standard Spark Plug CPR7EA-9 - NGK

Bujie standard NGK CPR7EA9.

Technical specifications:
- thread diameter: 10mm
- thread pitch: 1.0mm
- with resistor: yes
- resistor value: 5K Ohm
- thread length (including unthreaded part): 19mm
- hexagon diameter: 16mm
- terminal type: detachable nut
- electrode gap: 0.9mm
- heat range: 7

Applications:
Among the most important applications are: Honda CB 125 F / CBF 125 M / PCX 125 WW125 / PCX 150 WW150 / Honda SH 125 A i ABS / SH 150 A i ABS / Kawasaki KVF 750 G Brute Force EPS / VN 900 B CLASSIC / VN 900 C Custom / Yamaha XV 950 / XVS 950 A Midnight Star / YFM 700 FWAD Grizzly EPS / YFM 700 FWB Kodiak / YXE 700 R E Wolverine / YXM 700 E Viking / YXR 700 Rhino.

Complete application list can be found below.
