Standard Spark Plug CR6E - NGK

Bujie standard NGK CR6E.

Technical specifications:
- thread diameter: 10mm
- thread pitch: 1.0mm
- with resistor: yes
- resistor value: 5K Ohm
- thread length (including unthreaded part): 19mm
- hex diameter: 16mm
- terminal type: detachable nut
- electrode gap: 0.8mm
- heat range: 6

Applications:
Among the most important applications are: Arctic Cat Cat 400 / Cat 400 FIS / Cat 500 / Cat 500 FIS / Cat 700 FIS / TBX 500 / Masai A 700 / R 700 Drift / Suzuki LT-A 450 X KingQuad AXI 4X4 / LT-A 500 XP KingQuad AXI 4x4 Powersteering / LT-A 500 F Quadmaster 4x4 / LT-A 500 F Vinson 4X4 / Suzuki LT-A 700 X KingQuad 4X4 / LT-A 750 X KingQuad AXI 4X4 / LT-F 500 F Quadrunner 4X4 / VZ 1500 M1500 Intruder.

Complete application list can be found below.
