Transmission chain DID X-Ring - 520ZVM-X (gold / gold) - 110 links - DID

Lant transmisie DID X-Ring 520ZVM-X (gold / gold) - 110 links.

The DID 520ZVM-X chains are manufactured in Japan and each link is protected from moisture and dirt by an X-Ring. The main difference between X-Ring and O-Ring is that the former has two contact and sealing areas, while chains with O-Ring technology have only one contact point. As a successor to the high-performance DID ZVM2 model, the ZVM-X model has been given special attention to the loads that occur in the transmission system during everyday use, it has a lower weight compared to ZVM2, increased tensile strength, and very high wear resistance.

Specifications:
- pitch 520 (5/8 x 1/4)
- internal self-lubrication
- maximum efficiency
- high lifespan
- open chain - contains a link with a closing pin
- tensile strength (kg): 3970 kg
- color: gold / gold
- length: 110 links

Note: the applications of this chain (number of links - 110) are for the factory (standard) ratio. We recommend checking the length on the vehicle before ordering. If a different number of links is required, use this product and select the corresponding number of links: DID 520ZVM-X X-Ring chain (gold / gold) - link number selection.

Among the most important applications are: Aprilia RSV4 1000 R (2011-2016) / RSV4 1000 Factory APRC (2011-2015) / Kawasaki ZX-10R 1000 Ninja (2004-2005 / 2008-2010) / Kawasaki ZX-6R 636 / ZX-6RR 600 N Ninja (2005-2006) / Kawasaki ZX-9R 900 Ninja (1998-2003) / Suzuki GSX-R 600 / GSX-R 750 (2001-2005) / GSX-R 1000 (2001-2006) / Yamaha TZ 250 (1997-2003).

Complete application list can be found below.
