Piston Kit - Honda NSR125 / CRM125 R ('91-'03) (53.94-54.94mm) - Wossner

Forged piston kit Wossner for Honda NSR 125 / CRM 125 R manufactured between 1991-2003.

The kit includes piston, rings, pin, and clips.

Please select the piston size from the box above.

Technical specifications:
- cylinder diameter: 54.00mm
- thermal clearance: 0.06mm
- pin-to-cap distance (measured from the center of the pin): 30.00mm
- piston pin dimensions: 16x10x45mm.

Available piston sizes:
- A (53.94 mm)
- B (53.95 mm)
- C (53.96 mm)
- +0.50mm
- +1.00mm
